Othakalmandapam
Your Project is completed!
HIGHLIGHTS
Gated Community
100% Vaasthu
E.B Facilities
Road Facilities
Garden Area
Water Facilities
24/7 Camera
Childrens Park
Street Light
Parking
Sed do eiusmod tempor incididunt ut labore
Lorem ipsum dolor sit amet, consectetur adipisicing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat. Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur. Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum. Sed ut perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium, totam rem aperiam, eaque ipsa quae ab illo inventore veritatis et quasi architecto beatae vitae dicta sunt explicabo.
Sed do eiusmod tempor incididunt ut labore
Lorem ipsum dolor sit amet, consectetur adipisicing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat. Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur. Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum. Sed ut perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium, totam rem aperiam, eaque ipsa quae ab illo inventore veritatis et quasi architecto beatae vitae dicta sunt explicabo.
| Cement | Chettinad And Fenna (PPC 53 Grade) |
| Steel | Jsw, Wongen, Sun, Indrola. (Fe 500D) |
| Stone | 20mm For Concrete,40mm For Pcc |
| Brick | First Class Clay Brick (10.5 N/mm^2) |
| Sand | M Sand & P Sand |
| Main Door | Teak Wood |
| Room Door | Membrane Door |
| Main Windows | Teak Wood With Grill (12mm Polish Rod) |
| Other Windows | UPVC With M S Grill (12mm Polish Rod) |
| Window Glass | Pint Type (Upto 35 Per Sq Ft) |
| Flooring Tiles | 4’x2’ Vertified Tyiles (Upto 55) |
| Electrical Box | Metal Box |
| Switches | Legrand |
| Electrical Pipe | Supreme |
| Plumping Pipes | Concealed Pipe CPVC Outer Water Line PVC , waste water line PVC Supreme Brand |
| Sanitary Ware | Inner Material Parryware And Hindware Outer Water Tech |
| Paints | Inner Tracter Emulsion, Outer Asian |
TERMS & CONDITIONS
The General Specifications For Building To Be Constructed In 2021 Is Incorporated For Project Involve All Accepted Norms And Estimates Of Approved Building Constructions .Further ,Principle Amendments And Additions Include A General Review Of The Technical Requirements Updating The Indian Standards (Such As IS456,IS13920,SP16&SP34etc.) As Well As Incorporation Of Further Green Specifications To Be In Line . With The Builder’s Procurement Policy Please Refer The Summary Of Major Details Given Under.
The Detailed Specifications Given Here In After Are For The Items Of Works Described In The Schedule Of Quantities Attached Here In & Shall Be Guidance For Proper Execution Of Work To The Required Standards.
It May Also Be Noted That The Specifications Are Of Generalized Nature & These Shall Be Read In Conjunction With The Description Of Items In Schedule Of Quantities & Drawings. The Work Also Includes All Minor Details Of Construction Which Are Obviously & Fairly Intended And Which May Not Have Been Referred To In These Documents But Are Essential For The Entire Completion In Accordance With Standard Engineering Practice.
Unless Specifically Other Wise Mentioned ,All The Applicable Codes And Standards Published By The Indian Standard Institution And All Other Standards Which May Be Published By Them Before The Date Of Receipt Of Tenders, Shall Govern In All Respects Of Do Sing Workmanship Quality & Propitious Of Materials & Methods Of Testing, Methods Of Measurements Etc. Wherever Any Reference To Any Indian Standard Specifications Occurs In The Documents Relating To This Contract ,The Same Shall Be Inclusive Of All Amendments Issued To Or Revisions There Of, If Any Up To The Date Of Receipt Of Tenders.
In Case There Is No I.S.I Specification For The Particular Work, Such Work Shall Be Carried Out In Accordance With The Instructions N All Respects,& Requirements Of The Engineers-In-Charge. Wherever Any Reference To Any Indian Standard Specification Occurs In The Documents Relating To His Contract ,The Same Shall Be Inclusive Of All Issued There To Or Revisions There Of ,If Any, Up To The Date Of Receipt Of Tenders.
The Work Shall Be Carried Out In A Manner Complying In All Respects With The Requirements Of Relevant Bye-Laws Of The Municipal Committee/Municipal Corporation/Development Authority/Improvement Trust Under The Jurisdiction Of Which The Work Is To Be Executed Or As Directed By The Engineer-In-Charge And, Unless Otherwise Mentioned, Nothing Extra Shall Be Paid In This Account.
The Company Shall Maintain In Perfect Condition All Works Executed Till The Completion Of The Entire Work Allotted To Him. Where Phased Delivery Is Contemplated, This Provision Shall Apply To Each Phase.
- Main Door – 1 No – 3’ X 7’
- Window – 2 No – 4’ X 4’(With Granite Finishing)
- Switch Board 1 – 12 Model Box For Lighting And Fan Point And 2 No – 5 Amp Switch & Socket
- Switch Board 2 –12 Model Box For Lighting And Fan Point And 2 No – 5 Amp Switch & Socket
- Switch Board 3: Tv Point. 3nos 5amp Switch And Socket
- Window – 1 No – 3’X 4’
- Wash Basin . 1 No : Wall Mounted
- Switch Board 7: 8 Model Box For Lighting And Fan Point And 1 No – 20 Amp Switch & Socket
- Window – 2 No – 3’X 4’
- Countertop 2’ Deep For Two Sides With Granite Finishing
- S.S Sink With Sink Faucet 1no
- Only Provision For Water Purifier (Electrical And Water Inlet Only)
- Kadapa Shelves With Laft One Side
- Switch Board 4: 10 Model Box For Lighting And Fan Point And 1 No – 20 Amp Switch & Socket
- Switch Board 5: 2 No – 20 Amp Switch & Socket For Mixi And Grinder
- Switch Board 6: 2 No – 20 Amp Switch & Socket For Micro Oven
- Main Door – 1 No – 3’ X 7’
- Window – 2 No – 3’ X 4’
- Kadapa Shelves In 9” Inner Wall One Side
- Switch Board 8 – 12 Model Box For Lighting And Fan Point And 1 No – 5 Amp Switch & Socket
- Switch Board 9 –6 Model Box For Charging Point 2no – 5-Amp Switch & Socket
- Switch Board 10: Ac Point
- Door – 1 No – 2’ 6” X 7’
- Ventilator – 1 No – 2’ X 2’
- Wash Basin – 1no
- EWC (Floor Mount) – 1 No
- Wall Mixture – 1 No
- Geyser Electrical Provision Only
- Switch Board 11 – 2 Nos- One Way Switch; 1 No – 5 Amp Switch & Socket
- Interior Wall Painting – 3 Coat Putty; 1 Coat Primer; 2 Coat Emulsion
- Interior Wall Painting – 1 Coat Primer; 2 Coat Emulsion (Kitchen, Toilet & Utility)
- Ceiling Painting – 1 Coat Primer; 2 Coat Emulsion
- Exterior Wall Painting – 1 Coat Primer; 2 Coat Emulsion
- Exterior Wall Painting –3 Coat Putty Only In Elevation Work, 1 Coat Primer; 2 Coat Emulsion
- Main Door – 1 No – 3’ X 7’
- Window – 2 No – 3’ X 4’
- Kadapa Shelves In 9” Inner Wall One Side
- Switch Board 12 – 10 Model Box For Lighting And Fan Point And 1 No – 5 Amp Switch & Socket
- Switch Board 13 – 6 Model Box For Charging Point 2no – 5-Amp Switch & Socket
- Door – 1 No – 2’ 6” X 7’
- Ventilator – 1 No – 2’ X 2’
- IWC (Floor Mount) – 1 No
- Wall Mixture – 1 No
- Geyser Electrical Provision Only
- Switch Board 14 – 2 Nos- One Way Switch; 1 No – 5 Amp Switch & Socket
- Main door Brick steps with granite top finishing
- Outer And Inner Staircase Brick Steps With Tiles Finishing
- SS Handrail will be provided 304\18kg
- Switch Board 15 – 12 Model Box For Lighting And Fan Point And 1 No – 5 Amp Switch & Socket
- Door – 1 No – 2’ 6” X 7’
- Ventilator – 1 No – 2’ X 2’
- Covered With Loft (Only Shower & Toilet)
- Washing Machine Line Will Be Provided
- Switch Board 16 – 4 Nos- One Way Switch; 1 No – 20 Amp Switch & Socket
- Flooring – 4’ X 2’ Tiles (For All Room Floors)
- Utility Flooring – 1’ X 1’ Parking Tiles
- Toilet Flooring – 1’ X 1’ Non-Slippery Tiles
- Shower Wall Tiles – Upto 7 Feet
- Outer Toilet Wall Tiles – Upto 3 Feet
- Kitchen Wall Tiles – Upto Lintel
- Skirting Tiles Upto 3”
